Q MODEL COIN MECHANISM ASSEMBLY
| SI.# | Name | Part# |
|---|---|---|
| 2 |  | 2301563 |
| 2a | | 2301573 |
| 3 | | 9607093 |
| 4 | | 2032673 |
| 7 | | 6030501 |
| 9 | | 3060273 |
| 9a | | 3060283 |
| 10 | | 6030171 |
| 11a | | 2406483 |
| 11c | | 2032603 |
| 13 | | 5544599 |
| 14 | | 5650809 |
| 15 | | 5305049 |
| 16 | | 5429069 |
SI.# 2
Name Push Button Switch Assembly "ICE" 2301563
SI.# 2a
Name Micro-Switch Only 2301573
SI.# 3
Name Single Switch Plate 9607093
SI.# 4
Name Wiring harness 2032673
SI.# 7
Name Coin Door Assembly 6030501
SI.# 9
Name Cam Lock 3060273
SI.# 9a
Name Cam Lock Key 3060283
SI.# 10
Name Coin Box Assembly Frame 6030171
SI.# 11a
Name Vend Relay 120V 2406483
SI.# 11c
Name Vend Relay Wiring Lead 2032603
SI.# 13
Name Panel/Condenser Mounting Lockwasher 5544599
SI.# 14
Name Nylon Wire Harness Clip 5650809
SI.# 15
Name Thumbscrews #8-32 5305049
SI.# 16
Name Hex Nut - #8-32 5429069
